Setup a Digital Matter LoRaWAN Guppy Orientation Reference

Updated: Jan 2, 2019



This post shows you how to set up an orientation reference for the Digital Matter Guppy.


Hardware


The box




Inside the box



The screws are inside the unit


The unit




Orientation Reference


1. Draw orientation arrows on the package with a Sharpie [link]


Orientation


Image from [link]. More orientation notes at [link].


2. Print out this orientation guide

Available at [link].


3. Place unit face up in the package


Batteries should face out


The unit on the orientation diagram


4. Create a board for the orientation diagram


5. Tape the orientation diagram on


6. Before taping the Guppy down, get the serial programming cable


7. Plug it in


8. Close up and put the black rubberband around the unit


9. Tape everything down (Update: it does not appear that you can leave the cable connected)



Reference

Digital Matter logo from [link]
