ZC706 Unboxing

xilinx_logo_1

This post shares pictures of everything in the ZC706 Evaluation Kit from Xilinx.

The box:

zc706_box_front_2

zc706_box_back_3

zc706_box_right_side_4

zc706_box_right_side_5

The box opened:

zc706_box_opened_6

Removing the ZC706 from the packaging:

zc706_box_removed_7

zc706_unwrapping_8

zc706_unwrapped_9

The top of the ZC706 board:

zc706_board_top_10

The bottom of the ZC706 board:

zc706_board_bottom_11

The Limited Warranty:

limited_warranty_12

A note about additional resources available for using the ADV7511:

additional_recources_13

A voucher and proof of purchase (the bar code has been covered):

voucher_proof_of_purchase_14

A welcome letter including a manifest for components in the kit:

welcome_letter_manifest_15

A UK plug adapter in the plastic bag:

uk_plug_adapter_16

A German plug adapter in the plastic bag:

german_plug_adapter_17

An HDMI cable in the plastic bag

hdmi_cable_18

A Mini-B to Type-A (host connection) USB cable:

mini_b_type_a_19

A Micro-B to Type-A (host connection) USB cable:

micro_b_type_a_20

A US plug adapter:

us_plug_adapter_21

The top of the 12V/5A power supply

12v_5a_power_supply_top_22

The bottom of the 12V/5A power supply

12v_5a_power_supply_bottom_23

A Micro-B to Female Type-A OTG USB cable:

micro_b_female_type_a_24

A Micro-B end of the OTG USB cable:

micro_b_end_25

A Female Type-A OTG end of the OTG USB cable:

female_type_a_end_26

An Ethernet crossover cable

ethernet_crossover_cable_27

An 8GB class 4 SD card

8gb_sd_card_28

A plug for a PC power supply for when the ZC706 is used as a card in a PC

pc_power_supply_29

Front of Vivado 2015 media

front_of_vivado_2015_media_30

Back of Vivado 2015 media

back_of_vivado_2015_media_31

Front of 32-bit Fedora media

front_of_32_bit_fedora_32

Back of 32-bit Fedora media

back_of_fedora_32_bit_33
